Roundbottlecappingmachine-FuntionPackMachineryLtd.

Capping machine/

Round bottle capping machine


FUNTION PACK offers a wide variety of capping machine equipment to secure most cap types onto different of bottle types. Our capping machines utilize the advantage technologies to achieve the highest speeds and most accurately capped bottles on the market. We manufacture different styles of cappers. Our capping machinery is available from a low rate capping up to a high-speed capping system.



Model GX-200
Capping Speed 80-120 BMP
Bottle diameter 50-120 mm
Bottle height 60-200 mm
Cap diameter 20-120 mm
Power 1.3KW, 220v, 50-60HZ
         Dimensions (L*W*H)                2400mm*1400mm*1550mm
Weight 350kg

  • Product Detail
  • About us

GX-200 Round bottle capping machine is economical, and easy to operate. This in-line spindle capper handles a wide range of containers and offers a quick and easy changeover that maximizes production flexibility. The tightening discs are gentle which will not damage caps but with an excellent capping performance.

Round bottle capping machine
Round bottle capping machine

Key Features:

  • Sorting and feeding cap automatically
  • Different cap chute for different size of caps
  • Variable speed control
  • PLC control system
  • Rejection system for improperly capped bottles (Optional)
  • Stainless steel construction
  • 3 sets of tightening discs
  • No-tool adjustment

Industry Type(s)

  • Nutraceuticals
  • Candy
  • Agriculture
  • Pharmaceuticals
  • More industries
This automatic  plastic bottle capping machine is economical, self contained, easy to operate, equipped with auto teach programming touch screen. Built in microchip storing different job setting makes fast and easy changeover.

Major components:

NameBrand
PLCDELTA
RelaySCHNEIDER
BreakerSCHNEIDER
Switch powerMEANWELL
Detection sensorAUTONICS
Block cylinderAIRTAC(TAIWAN)
Solenoid valveAIRTAC(TAIWAN)
Surface stainless steel parts SS304

Many of Shanghai Funtion Pack Machinery’s customers have passed or are applying for GMP certification. and with good products and professional personnel and rich experience, the company has helped these customers improve efficiency and make their certification process more smooth. Funtion Pack can also provide “tailor-made” services according to customer needs, and specialize in customizing non-standard models for customers. Among the company’s products, there are high-end products with intelligent human-machine interface operation, high-speed equipment that packs more than 400 bottles per minute, and economical products that are stable and affordable, which can fully meet the different needs of various customers.

      Funtion Pack Machinery was established in Shanghai, PR China in 1985, since that, we have   dedicated to packaging machinery manufacturing and design for nearly 30 years. During so long time, we have extended our business to become a supplier of complete packaging line including bottle washer, unscrambler, filling and counting machine, inserting machine, labeling machine, capping machine, sealing machine, cartoning machine and so on. We believe that we possess rich experience and ability to meet a variety of requirements of you. Besides, we also provide very good after-sales service and solution of technology problem. We also provide training, on-site installation, documents support. We could make customized products based on different requirements of different customers.
