Capsulecountingmachine-FuntionPackMachineryLtd.

Counting machine/

Capsule counting machine



Specifications:
Model VS-8
Counting Speed 6000-8000 pieces/minute
Hopper capacity Approx. 20 liters
Bottle height 40mm-240mm
Bottle opening Φ25- 40 mm
Bottle diameter Φ45 mm – 60 mm
Size of tablet Φ2 mm – 20 mm
Size of capsule 00# – 5#
Clear soft gel OB, OV, F, R
Power 1.5KW, 220v, 50-60HZ
  Compressed air pressure   87 Psi
Dimensions (L*W*H)   1800mm×1540mm×1900 mm
Weight 550kg

  • Product Detail
  • About Us

The capsule counting machine utilizes advanced real-time image processing technology to enable highly accurate counting results.

The capsule counting machine represents a new concept, being a modular and completely real-time vision system. The unit combines high technology with simple operating procedures. IPC controlling uint allows very accurate and repeatable product feeding,  counting, and filling.

The capsule counting system consists of a single mainframe with fixed side panels, so the changeover is quick and easy, without tools. Cleaning is easy and quick, reducing maintenance.

Adopting a new Digital Camera System and advanced algorithm, so the machine handles a wide variety of tablets, pills, and hard and soft capsules with different shapes and sizes.

capsule counting machine
Capsule counting machine

Key features

  • Capsule counting machine CCD technology with high speed digital camera
  • Highly anti-dusty design
  • Suitable for various capsule with different transparency
  • Speeds up to 60 cpm based on 100-count bottles with vibration system
  • Counting accuracy: 100%
  • Operation stable and lower noise
  • Touch screen Control System which is easy to control
  • Simple Straight Forward Operator Controls
  • Stainless Frame

Industry Type(s)

  • Nutraceuticals
  • Candy
  • Agriculture
  • Pharmaceuticals
  • More industries
counting machine01
This soft tablet counter and filler combine 8-channel counting heads over a conveyor on a single frame to double the throughput without doubling the floor space, achieving speeds up to 60 CPM based on 100-count bottles. The machine handles a wide variety of candies, both hard and soft candies of different shapes, sizes, and properties.

Major components:

NameBrand
PLCDELTA
RelaySCHNEIDER
BreakerSCHNEIDER
Switch powerMEANWELL
Detection sensorAUTONICS
Block cylinderAIRTAC(TAIWAN)
Solenoid valveAIRTAC(TAIWAN)
Surface stainless steel parts SS304

Many of Shanghai Funtion Pack Machinery’s customers have passed or are applying for GMP certification. and with good products and professional personnel and rich experience, the company has helped these customers improve efficiency and make their certification process more smooth. Funtion Pack can also provide “tailor-made” services according to customer needs, and specialize in customizing non-standard models for customers. Among the company’s products, there are high-end products with intelligent human-machine interface operation, high-speed equipment that packs more than 400 bottles per minute, and economical products that are stable and affordable, which can fully meet the different needs of various customers.

Funtion Pack Machinery was established in Shanghai, PR China in 1985, since that, we have   dedicated to packaging machinery manufacturing and design for nearly 30 years. During so long time, we have extended our business to become a supplier of complete packaging line including bottle washer, unscrambler, filling and counting machine, inserting machine, labeling machine, capping machine, sealing machine, cartoning machine and so on. We believe that we possess rich experience and ability to meet a variety of requirements of you. Besides, we also provide very good after-sales service and solution of technology problem. We also provide training, on-site installation, documents support. We could make customized products based on different requirements of different customers.
